1308 Spherical PDC Cutters From China Supplier

1308 Spherical PDC Cutters adopt diamond powder and tungsten carbide substrates as its raw material,
it is a complex material which is made under high temperature and high pressure sintering.
Combine the hardness, wear-resistance and thermal conductivity with high impact toughness and strength of tungsten carbide.
Product Description

Description of 1308 Spherical PDC Cutters

1308 Spherical PDC Cutter is made of diamond  powder and tungsten carbide substrate. It has higher heat

durability and impact toughness, fast footage, high timeliness, economic and practical. Improved stress distribution

makes the bonding surface more solid, improves product reliability and service life, has a higher cost.

Specification of 1308 Spherical PDC Cutters

Coal mining and geological drilling series PDC cutter

Dimension

code

Diameter(D)

Height total

(H)

Height

diamond

Diamond

Chamfer

Carbide

Chamfer

08048±0.054 ±0.100.9-1.20.5×45°0.5×45°
0808
8±0.058±0.100.9-1.20.5×45°0.5×45°

1004

10±0.05

4 ±0.10

0.9-1.2

0.5×45°

0.5×45°

1204

12±0.05

4±0.10

1.2-1.4

0.5×45°

0.5×45°

1304

13±0.05

4±0.10

1.2-1.4

0.5×45°

0.5×45°

1308

13±0.05

8±0.10

1.4-1.6

0.5×45°

0.5×45°

We can provide customized pdc cutters as your requirements.

PDC cutter structure.jpg

The chamfer of PDC cutter is 0.2-0.5mm×45°, using this technology can improve the anti-abrasion ability, the effect is especially obvious when drilling into the heterogeneity stratum and can improve the durability and total footage.

Application of 1308 PDC cutter bits

PDC non core bit.jpg133 PDC sintered drill bits.jpgpdc drag bit.jpg

Packaging and shipping

Packaging  for 1308 Spherical PDC Cutters is in plastic box, 50 pieces or 100 pieces are in one box.

Samples are shipped by express, batch products are shipped by sea or by air.

Delivery time: 1-5 days for sample, 1-15 days for batch products.

pdc cutter inserts packaging and shipping.jpg


Oilfield PDC cutters

1308 oilfield PDC cutters.jpg1613 PDC cutters.jpg
